Calon Gloria 40 Hp
video

Calon Gloria 40 Hp

Strong 40HP Output – Delivers dependable power for demanding boating applications.
Quick Throttle Response – Provides smooth acceleration and confident handling.
Durable Construction – Built for reliable performance and easy long-term maintenance.
Recommended Boat Length: 4.8–6.5 m (16–21 ft)
Send Inquiry

Description

Technical Parameters

About Outboard



One of the biggest strengths of the Calon Gloria 40 HP is its excellent power-to-weight balance. As a 40HP two-stroke outboard, it delivers the strong acceleration needed for larger fishing boats, aluminum boats, and utility vessels without adding unnecessary weight to the transom. This combination helps improve boat handling and makes installation and maintenance more convenient.

The Calon Gloria 40 HP is built for users who need dependable performance in everyday operation. Its mature two-stroke design provides responsive throttle control and strong low-end torque, making it well suited for carrying passengers, fishing equipment, or commercial loads. Whether starting from a standstill or cruising over long distances, the engine offers steady and predictable power.

Designed with practicality in mind, the Calon Gloria 40 HP features a straightforward mechanical structure that simplifies routine servicing and reduces maintenance time. For distributors, commercial operators, and recreational boat owners alike, it is a reliable solution that combines proven performance, ease of maintenance, and long-term durability.





Specification of Each type



T40BS -- Manual start, tiller/back control, short shaft                                                       T40BL -- Manual start, tiller/back control, long shaft

T40BWS -- Electric start, tiller/back control, short shaft                                                    T40BWL -- Electric start, tiller/back control, long shaft

T40FWS -- Electric start, remote/front control, short shaft                                                T40FWL -- Electric start, remote/front control, long shaft

T40FWTS -- Electric start, electric tilt, remote/front control, short shaft                         T40FWTL -- Electric start, electric tilt, remote/front control, long shaft



  T40BS T40BL T40BWS T40BWL T40FWS T40FWL T40FWTS T40FWTL
Length (mm) 1073 1073 1073 1073 675 675 675 675
Width (mm) 402 402 402 402 362 362 362 362
Height (mm) 1237 1364 1237 1364 1237 1364 1237 1364
Dry Weight (kg) 76.00 78.00 78.00 82.00 78.50 80.50 81.50 85.00
Transom Height (mm) 424 550 424 550 424 550 424 550
Rated Power (kw) 29.4 29.4 29.4 29.4 29.4 29.4 29.4 29.4
Max RPM (Revolutions/min) 4500-5500 4500-5500 4500-5500 4500-5500 4500-5500 4500-5500 4500-5500 4500-5500
Stroke 2 2 2 2 2 2 2 2
Number of Cylinders 2 2 2 2 2 2 2 2
Bore x Stroke 80*70 80*70 80*70 80*70 80*70 80*70 80*70 80*70
Displacement (cc) 703 703 703 703 703 703 703 703
Exhaust System Center Exhaust Center Exhaust Center Exhaust Center Exhaust Center Exhaust Center Exhaust Center Exhaust Center Exhaust
Cooling System Water Cooling Water Cooling Water Cooling Water Cooling Water Cooling Water Cooling Water Cooling Water Cooling
Starting System Manual Manual Manual / Electric Manual / Electric Manual / Electric Manual / Electric Manual / Electric Manual / Electric
Steering System Tiller Tiller Tiller Tiller Remote Remote Remote Remote
Ignition System CDI CDI CDI CDI CDI CDI CDI CDI
Spark Plug BR7HS-10 BR7HS-10 BR7HS-10 BR7HS-10 BR7HS-10 BR7HS-10 BR7HS-10 BR7HS-10
Fuel Tank 24L 24L 24L 24L 24L 24L 24L 24L
Gear Ratio 2.00(26/13) 2.00(26/13) 2.00(26/13) 2.00(26/13) 2.00(26/13) 2.00(26/13) 2.00(26/13) 2.00(26/13)
Gear Shift F-N-R F-N-R F-N-R F-N-R F-N-R F-N-R F-N-R F-N-R
Propeller 11 1/8×13 11 1/8×13 11 1/8×13 11 1/8×13 11 1/8×13 11 1/8×13 11 1/8×13 11 1/8×13
Idle Speed (r/min) 1100±50 1100±50 1100±50 1100±50 1100±50 1100±50 1100±50 1100±50



Details of T40



40 hp outboard motor
40 hp marine engine
2 stroke 40 hp




Quality is reflected in every detail of the T40. From carefully selected materials to precision machining and optimized assembly, each component is designed to deliver reliable performance in demanding marine environments. Key structural parts are engineered for durability, while upgraded anti-corrosion treatments help extend service life and maintain consistent operation.

Attention is also given to the small details that matter in everyday use. Reinforced brackets, well-protected wiring, secure sealing, and durable surface finishes all contribute to improved reliability and easier maintenance. Every T40 undergoes inspection and functional testing before shipment to ensure it meets our quality standards.



Factory



outboard motor manufacturer
outboard motor supplier
outboard motor factory




Behind every outboard motor is a team committed to precision manufacturing and consistent quality. Our factory is equipped with modern production lines, precision machining equipment, and dedicated testing facilities, enabling us to maintain stable production and reliable product performance.

From component inspection to final assembly and functional testing, every production stage follows standardized quality control procedures. As a factory-direct manufacturer, we also welcome customers to visit our facility for factory audits, product inspections, and technical discussions, ensuring transparency and confidence throughout the cooperation.



calon gloria
calon gloria
calon gloria


A dedicated team driving quality, innovation, and long-term partnership.



Customer Feedback



2 stroke 40 hp outboard
2 stroke 40 hp marine engine
2 stroke 40 hp outboard motor




Every photo tells a real story on the water. From peaceful fishing trips to family outings and recreational boating, our outboard motors continue to support customers in different environments and applications. Designed to fit a variety of boat types, they provide dependable power for everyday adventures.





FAQs



1. What types of boats is the T40 suitable for?
A: The T40 is ideal for aluminum boats, fiberglass fishing boats, center-console boats, utility boats, patrol boats, and other medium-sized vessels requiring dependable 40HP performance.



2. What types of water can your outboard motors be used in?

A: Our motors are suitable for both freshwater and saltwater environments.



3. What battery specifications do you recommend for electric-start models?

A: 12V 40A battery
